■General Technical Characteristics 一般特性

Metallized polypropylene film

金属化聚丙烯膜

Low loss at high frequency

高频损耗小

Small inherent temperature rise

内部温升小

Plastic case (UL94 V-0), epoxy resin sealing

塑胶外壳（UL94 V-0 ), 阻燃环氧填充

 ■Electrical Characteristics 电气特性

Reference standard 引用标准:           GB/T 14579 (IEC60384-17)

Climatic Category 气候类别:             40/105/56

Rated Temperature 额定温度:           85°C

Operating Temperature Range:           -40°C ~ 105°C

工作温度范围:                          (+85°C to +105°C: decreasing factor 1.25% per °C for U_R)

Rated Voltage 额定电压:                400VAC, 500VAC, 600VAC, 700VAC, 900VAC

Capacitance Range 电容量范围:         0.00047µF ~ 0.15µF

Capacitance Tolerance 电容量偏差:      ±5% (J), ±10%(K)

Dissipation factor 损耗角正切:           ≤10x10^-4 Measured at 1KHz and 20°C.

Test Voltage 耐电压:                   1.6U_R for 5 sec.

Insulation resistance 绝缘电阻:          ≥100 000MΩMeasured at 20°C, 100V and 1 min.

Maximum Pulse Rise Time(dV/dt) 最大脉冲爬升速率:

If the working voltage (U) is lower than the rated voltage (U_R), the capacitor can be worked at a higher dV/dt. In this case, the maximum allowed dV/dt is obtain by multiplying the left value with U_R/U.

若实际工作电压U比额定电压 U_R低，电容器可工作在更高的dV/dt场合，这样dV/dt允许值应为左表值乘以U_R/U。
